Phenol bearing

「Phenol bearing」

Phenol bearings are mainly used in different kinds of pumps, stern shafts, valves, blending fluid mechanics. In the structure, it is suitable for horizontal axis, vertical axis and inclined axis. It can works in temporary dry condition, in the place of water disconnection or seawater, or liquor (acid, organic solution oil), in the place of electric or magnetic insulation needed and in the steam condition.

Main features of Phenol bearings：
●Performance better after contacting with water, do not rust (need no lubrication of oil or grease);
●Light, non-magnetic;
●Resistant to water, oil and drugs;
●Shaped complicatedly
●Insulating quality and static and preventional function
●Compared with mental bearings, it has foreign body stiffen function, impact resistance and anechoic function.
●Heat-resisting quality, abrasion-resisting quality, reasonable price
●Non-magnetism
●The burying characteristics of the alien substance, impact resistance, a silence effect are superior to a nonmetal bearing.
●Heat resistance

Use：
●Dry place
●It is a place using the water irregularly
●A river, seawater
●Medicine（Acid、Organic solvent、Oil）
●Do not want to give magnetic force
●The part which I want to insulate
●In steam

In the aspects of choosing basic material and self-adding lubrication, KTT effectively control the line expanding of phenol resin bearings.It reaches to 1*10^-5°C^-1 in minimum and solves the problem of distortion of PTFE.

The maximun diameter is 750 millimeters. If you want specifications and specific design information of product, please contact with us. Pump and bearing work in water- gas mixture condition for 60 minutes.（suitable for dry condition）
